Cold Room

Cold Room
Cold Room Cold Room Cold Room
Customization Ranges

Cooling capacity: -50℃~15℃
With extensive experiene in the cold room, Icesource has been designing, constructing, and installing controlled environmental chambers for over a decade. Stock and custom cold rooms can be provided to realize precise control of temperature, humidity, gas, and lighting with highly energy efficient components for a wide variety of applications.

Cold Room Specifications
  • Temperature range: -60°C to +20°C (-60°F to +68°F)
  • Size: customized
  • Functions: fresh preserving, freezing, quick-freezing, fire-proof, explosion-proof, air-conditioning
  • Fully automatic control system
  • Easy to install and dismantle
  • Temperature alarm
  • Control box: Digital indicator
  • PLC control system (SIMENS)
  • Insulation material: Polyurethane (PU)
  • Type of door: Sliding door/swing door
  • Size of door: customized as per request
  • Cooling method: air cooling, water cooling
  • Refrigeration unit: Copeland, Bitzer, Hitachi, Franscold and others.
  • Local power supply: 380V or 220V, single phase or three phase, 50Hz or 60Hz
Examples of Walk-in Cold Room

Our walk-in controlled environment rooms provides efficient and precise environmental controls for various applications inlcuding: GMP Storage and Cold Storage for medical products, fish and meat, fruit and vegetable, coffee beans, tea leaves, and fresh foods. Typical temperatures for our cold rooms range from of 0°C to 10°C.

  • Examples of Walk-in Cold Room
  • Examples of Walk-in Cold Room
  • Examples of Walk-in Cold Room
  • Examples of Walk-in Cold Room
Applications of Cold Room
Storage products Storage temperature approach
Vegetable, fruit storage -5 to 5℃ or above
Drink, beer storage 2 to 8℃ or above
Meat, fish freeze storage -18 to -25℃ or above
Medicine storage 2 to 8℃ or above
Cold room temperature Thickness of wall and roof panel
5~15°C 75mm
-15~5°C 100mm
-15~-20°C 120mm
-20~-30°C 150mm
lower than -30 degree 200mm

Different cold rooms have different temperatures and thus need to use Polyurethane sheet of different thicknesses for insulation.

Features
  • Main configurations for a cold room: compressor, condenser, oil separator, heat exchager, controller, solenoid valve;
  • Tight temperature control for reliability and accuracy;
  • The cold storage room can be custom built to work with any space constraints for various applications;
  • Conditioning system in the freezer room can be easily replaced or relocated because of simple connections;
  • Color steel plate, stainless steel plate and aluminum plate can be optionally used in the cold room;
  • Superior quality PU panels offer good heat insulation performance;
  • Refrigeration compressors from renowned international brands are equipped, with low noise and energy saving;
  • Adopts fully automatic microcomputer controller with digital display;
  • Uses explosion-proof LED lights in the controlled environmental rooms;
  • Keeps constant temperature due to the temperature monitoring system;
  • Custom cold storage size available;
  • The refrigeration system is equipped with the outstanding cooling system.

Our staff and factory trained technicians are all certified and credentialed professionals, enabling them to explain technical details, to provide custom cold storage solutions to our customers, and to troubleshoot potential issues. When it comes to a new cold room, icesource will be the right place for your individual cold storage equipment.

  • Medical Cold Storage
    1. The medical cold storage mainly stores various kinds of medical products that cannot be preserved under normal temperature conditions. Read More
    2. Medical Cold Storage
  • Ice Cold Storage
    1. Normally, the ice made by the ice machine needs to be stored in time to avoid melting. The ice cold storage design varies depending on the user's applications or ice types. Read More
    2. Ice Cold Storage
  • Fruits and Vegetables Cold Room
    1. Fruits and vegetables cold room is a cold storage facility to preserve fruits and vegetables. The low temperature can reduce the incidence of pathogenic bacteria and the decay rate of fruits and vegetables. Read More
    2. Fruits and Vegetables Cold Room
  • Containerized Cold Storage
    1. The containerized cold storage is constructed with a cold storage installed inside the container, greatly facilitating transportation. The cold storage is completely assembled and all refrigeration units ... Read More
    2. Containerized Cold Storage
  • Controlled Atmosphere Cold Storage
    1. The controlled atmosphere cold storage, also known as air-conditioned warehouse, is the most advanced preservation method for fruits and vegetables. Read More
    2. Controlled Atmosphere Cold Storage
  • Frozen Meat Cold Storage
    1. Frozen meat cold storage is a scientific solution for preserving the perishable meat. Meat foods lose their value of usage due to enzyme decomposition, oxidation, microorganisms growth and reproduction. Read More
    2. Frozen Meat Cold Storage
  • Quick Freezing Cold Storage
    1. Low-temperature quick-freezing plays a vital role in ensuring long-lasting preservation of foods. Rapid cooling can perfectly maintain the quality and taste of the food. The temperature of the quick freeze cold storage generally ranges from -15°C to -35°C. Read More
    2. Quick Freezing Cold Storage
