Automatic Ball Ice Machine
Ice Making Machine
Automatic Ball Ice Machine
Automatic Ball Ice Machine Automatic Ball Ice Machine Automatic Ball Ice Machine

Automatic Ball Ice MachineSingle-Head Ball Ice Maker

Effortless and efficient, the automatic ball ice machine is designed for high-quality, automated ice ball production, enhancing productivity while ensuring safety and durability. This ice making machine is ideally suitable for modern ice processing demands

Request a Quote
  • Automatic Ball Ice Machine
  • Automatic Ball Ice Machine
  • Automatic Ball Ice Machine
  • Automatic Ball Ice Machine

Compared to traditional single-head manual ice ball machine, the automatic ball ice machine model integrates advanced automation features such as automatic ice transfer, ice chip protection, ice chip collection, and automated ice ball collection and transfer. Its key advantages include:

    1. Automatic Ball Ice Machine
    2. Enhanced efficiency
      Production capacity has tripled compared to traditional manual machines, significantly boosting output.

    1. Automatic Ball Ice Machine
    2. Automatic ice chip collection
      Reduces the need for frequent manual cleaning, lowering labor intensity and saving time.

    1. Automatic Ball Ice Machine
    2. Durability and protection
      Equipped with ice chip protection to prevent corrosion and damage to the transmission components, ensuring long-lasting performance.

    1. Automatic Ball Ice Machine
    2. High degree of automation
      Automated ice ball reception, transfer, and collection enable seamless integration with automated production lines for continuous processing and higher productivity.

    1. Automatic Ball Ice Machine
    2. Safety and ease of maintenance
      Features protective covers for exposed moving parts to ensure operator safety. The simple structure provides ample maintenance space, making repairs and upkeep convenient.

Specifications
Machine size (L×W×H) 1.83×1.83×2.1m
Working environment clean workshop -10℃ to +35℃
Voltage single phase 220V/50Hz/60Hz
Air pressure 0.4-0.6Mp
Power 5kW
Noise level ≤70db
Ice chip removal manual cleaning (standard)/automatic collection (optional)
Loading & unloading manual operation
Ball ice arrangement automatic arrangement
Production cycle 20-30 seconds per cycle
  • Automatic Ball Ice Machine
Features
  • Each automatic ice ball machine is equipped with original and forward position detection capabilities, ensuring precise and reliable operation at all times.
  • Features an MCGS touchscreen, offering a user-friendly interface with support for both English and Chinese. The touchscreen allows operators to switch between manual and automatic modes, select machine models and programs, diagnose faults, monitor system status, count workpieces, and adjust processing cycles effortlessly.
  • A comprehensive fault alert system notifies operators of issues such as low air pressure, mechanical malfunctions, or misaligned workpieces, ensuring smooth and safe operation.
  • The automatic ball ice machine is equipped with a dual alert mechanism, combining a three-color indicator light and a buzzer to provide both visual and audible notifications. Additionally, it includes a manual or automatic reset-to-home function for seamless operation recovery.
